DG-1 CO Carbon Monoxide Detector

DG-1 CO is a microprocessor-based carbon monoxide detector. It is recommended for installation in rooms where there is a risk of carbon monoxide presence, such as boiler rooms, near fireplaces, heaters, gas stoves, garages, etc. The detector detects dangerous gas concentration levels exceeding the threshold within a specified time. Due to the properties of carbon monoxide, the detector should be installed at a height of approximately 1.5 m.

The digital gas detection algorithm and temperature compensation function ensure proper operation over a wide temperature range and resistance to false alarms. Thanks to the built-in buzzer and red LED indicator, the DG-1 CO detector can operate as an autonomous detection and signaling device, but it is also adapted for integration with an alarm system.

The self-diagnostic function continuously monitors the power supply voltage and the correct operation of the gas sensor, ensuring reliable operation of the detector. The device is equipped with a tamper switch.

FEATURES

• Digital signal analysis
• Optical and acoustic signaling of threshold concentration exceedance
• Low power consumption
• Full self-diagnostics
• Red LED indicator
