> >Heat pump air-water CH and DHW AIRMAX2 16 GT - 30 GT

Heat pump air-water CH and DHW AIRMAX2 16 GT - 30 GT

Heat pump air-water CH and DHW AIRMAX2 View larger
Previous Next

⛔ Product unavailable

Manufacturer: GALMET
GALMET

Discontinued product

Payment and delivery

Transport Costs: Individual calculation
(After placing your order we will send you a non-binding offer containing delivery costs.)

Payment methods for the goods:

Bank transfer – eligible for a 2% discount for orders from Poland (others without discount)
Cash on delivery – always without discount, available only in Poland and the Czech Republic (up to 8,000 PLN or 16,000 CZK, rest in bank trasfer)
P24 – operator’s payment gateway, no discount for orders from Poland, others +2%

Add to wishlist

Total Rating Total Rating:

0
0/5 - 0 reviews

View ratings
0 1 2 3 40
0 1 2 3 00
0 1 2 0 10
0 1 0 1 20
0 0 1 2 30

 Add Review View Reviews View Reviews

Accessories



Made in Poland

SpecificationunitAirmax26 GTAirmax29 GTAirmax212 GTAirmax215 GT
catalogue number09-26060009-26090009-26120009-261500
heating power(A7W35)1kW6,178,1111,0013,93
electrical powerkW1,411,762,333,02
COP-4,374,614,724,61
heating power(A2W35)1kW4,636,098,3110,07
electrical powerkW1,711,772,322,84
COP-3,283,443,583,55
heating power(A7W55)1kW5,527,319,8312,54
electrical powerkW2,132,713,524,30
COP-2,592,702,792,92
SCOPtemperate climate (W35)13,553,653,944,01
seasonal space heating efficiency%139,2143,0154,6157,5
ERP energy efficiency class-A+A+A++A++
SCOPtemperate climate (W55)12,842,963,073,09
seasonal space heating efficiency%110,8115,5119,6120,6
ERP energy efficiency class-A+A+A+A+
connection stubscal1
maximum flow temperature of the heating circuit°C57
voltage and frequency of power supplyV/Hz400/50
dimensions (height x width x depth)mm730 x 1295 x 5201305 x 1295 x 520
weightkg110115140145
air flowm3/h3000350050006000
the power of the electric heaterkW7
sound power2dB65,066,570,073,3
defrosting method-reversing the circulation
inrush currentA284351,562
number of fanspcs.12
refrigerant-R410A
amount of factorkg2,13,1
maximum working temperature°C30
minimum working temperature°C-20
maximum flow temperature°C57
1According to the EN 14511; A - air temperature; W - heated water temperature range.
2According to the EN 12102
GALMET
  • High COP value: up to 4,72 (A7W35).1
  • The highest possible energy efficiency class A++.
  • Ability to obtain grants in Germany - included on the BAFA list.
  • Intelligent controller with a colour touch-screen.
  • Weather system adjusts the heat pump's performance to the weather conditions.
  • Ability to set up the work schedule to both the heat pump and the circulation pump.
  • Room thermostat included.
  • Reliable scroll compressor and an electronic expansion valve that maximizes performance.
  • Evaporator with a hydrophobic layer.
  • Modulating fans with aerodynamically optimized blades.
  • Electronic circulation pump.
  • Soft start - option.
  • Easy installation.
  • Working range up to -20°C.
  • Ability to purchase a dedicated plate heat exchanger (glycol-water) for the existing water installation.

Data sheet

Width [ mm ]1,295
Depth [ mm ]520
InstallationFloor, External
Warranty 5 years
